SPECIFICATIONS

Brand Name: NoEnName_Null

Condition: New

Detailed Description: IC GATE DRVR LOW-SIDE 8-SOIC

Factory Pack Quantity (Pcs): 2000

Hign-concerned Chemical: None

Manufacturer Product Number: IXDN604SIATR

Mfr: IXYS Integrated Circuits

Mounting Style: SMD/SMT

Operating Temperature: -40°C ~ 125°C (TA)

Origin: Mainland China

Packaging: Reel

Product Type: Gate Drivers

Quantity: 1

Subcategory: PMIC - Power Management ICs

Supplier Device Package: 8-SOIC (0.154", 3.90mm Width)

Type: SWITCH

Unit Weight / single: 0.2g

Voltage - Supply (Vcc/Vdd): 4.5V ~ 35V

IXDN604SIATR

The IXDD604/IXDF604/IXDI604/IXDN604 dual high-speed gate drivers are especially well suited for driving the latest IXYS MOSFETs and IGBTs. Each of the two outputs can source and sink 4A of current while producing voltage rise and fall times of less than 10ns. The input of each driver is virtually immune to latch up, and proprietary circuitry eliminates cross conduction and current "shoot-through." Low propagation delay and fast, matched rise and fall times make the IXD_604 family ideal for high-frequency and high-power applications. The IXDD604 is a dual non-inverting driver with an enable. The IXDN604 is a dual non-inverting driver, the IXDI604 is a dual inverting driver, and the IXDF604 has one inverting driver and one non-inverting driver. The IXD_604 family is available in a standard 8-pin DIP (PI), 8-pin SOIC (SIA), 8-pin Power SOIC with an exposed metal back (SI), and an 8-pin DFN (D2) package.
