Módulo Convertidor Boost DC 3.7V a 1800V Step-Up Generador Pulso Arco Alto Voltaje
Módulo Convertidor Boost DC 3.7V a 1800V Step-Up Generador Pulso Arco Alto Voltaje
Precio habitual
$9.603 CLP
Precio habitual
$12.602 CLP
Precio de oferta
$9.603 CLP
Precio unitario
por
Los gastos de envío se calculan en la pantalla de pago.
No se pudo cargar la disponibilidad de retiro
SPECIFICATIONS
Brand Name: Aideepen
Certification: None
Input current: Max. 2A
Input voltage: 3-4.2V
Model Number: DC 3.7V to 1800V Boost Converter
Origin: Mainland China
Output Type: SINGLE
Size: 41.5mm*26mm
Type: DC/DC Converters
is_customized: Yes
Feature:
1. This is a high-voltage, low-current, low-power booster module, which can increase the low voltage of 3.7v to 1800v high voltage.
2. If you want to increase the instantaneous discharge current, you can output and connect a large-capacity, high-voltage capacitor
3. It is recommended to use four air conditioning compressors with CBB65 capacitors and 450v in series
4. Continuous operation, maximum discharge distance :1.5mm
5, suitable for a variety of DIY, can be used in middle school science experiments, electronic instruments, negative ion generator, scientific small production, etc.
Product Introduction:
Many friends do not know what is voltage, current, power, the error of high voltage that the current is large or large power, voltage unit is volt v, current unit is ampere A, power unit is watt w, current times voltage is equal to power. This is a high-voltage, low-current, low-power booster module, which can increase the low voltage of 3.7v to 1800v high voltage. Uses: middle school science experiment, electronic instrument, negative ion generator, scientific small production, etc.
Product parameters:
Input voltage :3-4.2V
Input current: Max. 2A
No-load current :130MA(4.2v voltage)
Output voltage :2000V (low battery voltage, output voltage will also be low)
Maximum discharge distance :1.5mm
Continuous operation
Size :41.5mm*26mm, PC board thickness: 1.6mm
Instructions for use:
In the case of using this module, if you want to increase the instantaneous discharge current, you can output and combine large-capacity, high-voltage capacitors (four air conditioning compressors CBB65 capacitors are recommended, 450v is used in series, the capacity size is selected according to your needs), such as the mousetrap made by customers, if you want to increase the discharge distance, higher voltage is required, this model has no way. I have to choose something else. If you feel that the discharge sound is small, you can output a parallel 2000v capacitor (which will reduce the discharge frequency). The discharge frequency of the sense is slow, and the frequency is determined by the power, which cannot be changed.
See a friend after purchasing the output voltage, the ordinary multimeter is not such a high voltage range, directly with 1000V test, the first measurement is not accurate, the second high voltage may cause the multimeter to burn out, you can use resistance voltage measurement, with two or three 3M OHMs in series after parallel at the output end, with a digital multimeter to measure the voltage on one of the resistors, three resistors in series, three resistors in series. The measurement voltage reading is multiplied by three, and the measurement results of two are multiplied by two. Because the internal resistance of the meter is low at the time of measurement, the high voltage and small current test will produce a large error (the test voltage is small), it is not recommended to use the pointer meter for measurement.
The output of 3V voltage input is about 1500v, 3.7v input is about 1800V, and 4.2V input is about 2000V.
Note:
The board has a high voltage capacitor, which may leave excess power after use!
High pressure danger, use need to pay attention to safety!
Unable to release an arc.
