π antenna network design, multi-channel satellite signal reception, impedance matching (50Q), antenna VSWR is less than 1.6, giving full play to the advantages of module receiving power, so as to have strong star search performance and accurate positioning. The module provides antenna detection and short-circuit protection functions inside, so as to play a better protection role in practical applications, built-in high-precision electronic compass QMC5883, with FLASH, can change the configuration, power failure is not lost, support GPS, BDS, GALILEO and other satellite systems

Brand：HAKRC

Model：GPS

Model: HAKRC M10

Chip: M10050

Satellite systems: GPS, BDS, GALILEO

Baud rate: 4800bps- 921600bps, default: 115200bps

Output protocols: NMEA, UBX

Update frequency: 0.25Hz-18Hz, default 10Hz

Flash: With FLASH, the configuration can be changed, and the power is not lost when the power is off

Tracking sensitivity: -166dBm

Speed accuracy: 0.05m/s

Maximum speed: 500m/s

Acceleration due to gravity: <4G

Maximum height: 80,000m

Horizontal Accuracy: 2.0m CEP (Ideal Environment)

Cold start: 27s (ideal environment)

Hot start: 1s (ideal)

Input voltage: 5.0V

Input current: 15mA

Operating temperature: -40C~+85°C

Compass: QMC5883 with an electronic compass inside

Size: 25x25x8mm

Weight: 12.35g
