Product characteristics

1.the product is easy to install, input out plug terminal, reserved hole welding

hole for use.

2. The four corners have fixed mounting holes to prevent power failure caused by

movement/vibration. The straight length of fixed holes is 3.2mm.

3. Universal input voltage: 85-264V AC or 110-370V DC.

4. high efficiency, high power density, low output ripple noise, double output,

control circuit output voltage precision (VO1).

5. High isolation of input and output.

6.over current protection, short circuit protection and temperature protection.

7.output built-in double LCp filter, no external circuit.

Input characteristic

Ac input (VAC) : 85-264VAC

Dc input (VDC) : 110-370VDC

Frequency range (Hz) : 47-63Hz

Input current (A) : 1/115VAC 0.5/230VAC

Surge current (A) : Cold start :20A/230VAC

Standby power consumption (mW) : ≤1W/230VAC

Operating temperature (°C) : -30-70 °C

Operating humidity (RH) : 20-90%RH, non-condensing

Temperature drift coefficient: +0.02%/°C

Storage temperature and humidity: -40~+85℃ 10-95%RH

Switching frequency (KHz) : 20-65KHz
