SPECIFICATIONS

Brand Name: NoEnName_Null

Condition: New

Detailed Description: IC SUPERVISOR 1 CHANNEL

Factory Pack Quantity (Pcs): 2500

Hign-concerned Chemical: None

Manufacturer Product Number: TL7712AIDR

Mfr: Texas Instruments

Mounting Style: SMD/SMT

Operating Temperature: -40°C ~ 85°C (TA)

Origin: Mainland China

Packaging: Reel

Product Type: Supervisory Circuits

Quantity: 1

Subcategory: PMIC - Power Management ICs

Supplier Device Package: 8-SOIC (0.154", 3.90mm Width)

Type: SWITCH

Unit Weight / single: 0.2 g

Voltage - Supply (Vcc/Vdd): -

is_customized: Yes

TL7712AIDR

Description The TL77xxA family of integrated-circuit supply-voltage supervisors is designed specifically for use as reset controllers in microcomputer and microprocessor systems. The supply-voltage supervisor monitors the supply for undervoltage conditions at the SENSE input. During power up, the RESET output becomes active (low) when VCC attains a value approaching 3.6 V. At this point (assuming that SENSE is above VIT+), the delay timer function activates a time delay, after which outputs RESET and RESET go inactive (high and low, respectively). When an undervoltage condition occurs during normal operation, RESET and RESET go active.
