SPECIFICATIONS

Brand Name: NoEnName_Null

Condition: New

Detailed Description: IC GATE DRVR HALF-BRIDGE

Factory Pack Quantity (Pcs): 2500

Hign-concerned Chemical: None

Manufacturer Product Number: UCC27201DR

Mfr: Texas Instruments

Mounting Style: SMD/SMT

Operating Temperature: -40°C ~ 140°C (TJ)

Origin: Mainland China

Packaging: Reel

Product Type: Gate Drivers

Quantity: 1

Subcategory: PMIC - Power Management ICs

Supplier Device Package: 8-SOIC (0.154", 3.90mm Width)

Type: SWITCH

Unit Weight / single: 0.2 g

Voltage - Supply (Vcc/Vdd): 8V ~ 17V

is_customized: Yes

UCC27201DR

Description The UCC2720x family of high-frequency N-channel MOSFET drivers include a 120V bootstrap diode and high-side and low-side drivers with independent inputs for maximum control flexibility. This allows for N-channel MOSFET control in half-bridge, full-bridge, two-switch forward, and active clamp forward converters. The low-side and the high-side gate drivers are independently controlled and matched to 1ns between the turnon and turnoff of each other. An on-chip bootstrap diode eliminates the external discrete diodes. Undervoltage lockout is provided for both the high-side and the low-side drivers forcing the outputs low if the drive voltage is below the specified threshold. Two versions of the UCC2720x are offered. The UCC27200 has high noise immune CMOS input thresholds while the UCC27201 has TTL compatible thresholds.
